22318 CC W33 Roller Excavator Bearing
Roller Bearing 22318 CC W33 With Excellent Roller Bearing Lubriion
Bearing Details
Roler bearing 22318 CC W33 with excellent roller bearing lubriion design & concept :
Shaker Screen Bearings spherical roller bearings are double row,
self-retaining units comprising solid outer rings with a concave
raceway, solid inner rings and barrel rollers with cages. The inner
rings with cylindrical or tapered bores.
It has two rows of rollers, a common sphered outer ring raceway and
two inner ring raceways inclined at an angle to the bearing axis.
The centre point of the sphere in the outer ring raceway is at the
bearing axis. Therefore, the bearings are self-aligning and
insensitive to misalignment of the shaft relative to the housing,
which can be caused, for example, by shaft deflection. They are designed to accommodate heavy radial loads, as well as heavy
axial loads in both directions.
Spherical Roller Bearings dimensional series are:
- 21300 Series - ISO Dimension Series 13 Spherical Roller Bearings
- 22200 Series - ISO Dimension Series 22 Spherical Roller Bearings
- 22300 Series - ISO Dimension Series 23 Spherical Roller Bearings
- 23000 Series - ISO Dimension Series 30 Spherical Roller Bearings
- 23100 Series - ISO Dimension Series 31 Spherical Roller Bearings
- 23200 Series - ISO Dimension Series 32 Spherical Roller Bearings
- 232 / Series - Extra Large ISO 32 Series Spherical Roller Bearing
- 23900 Series - ISO Dimension Series 39 Spherical Roller Bearings
- 24000 Series - ISO Dimension Series 40 Spherical Roller Bearings
- 24100 Series - ISO Dimension Series 41 Spherical Roller Bearings
- 29000 Series - ISO Dimension Series 90 Spherical Thrust Roller
Bearings
Product Display
Details Images
BEARING KNOWLEDGE
Inspection of bearing and judgment :
In order to determine whether removing bearings can be used to
check after the bearings clean, carefully check the roller surface,
scroll, status of the mating surfaces, wear of the cage, the
increase in bearing clearance and there's no falling damage,
abnormal size precision. Non-separation of small ball bearings,
supporting inner rings with one hand horizontally, rotate the outer
ring to confirm in a smooth rotation State. Tapered roller bearings
are separable bearings, rolling element and the Raceway in the
outer ring can be respectively checked. Larger bearings cannot
rotate, check rolling element and the Raceway, cage, sidewall
surface appearance. the importance of as high as possible shall be
carefully inspected.
Tips : Spherical roller bearing suffix meaning :
| Suffixes - Internal design |
| CA, CAC | Retaining flanges on the inner ring, guide ring centred on the
inner ring, machined brass cage |
| CC(J), CJ | Flangeless inner ring, guide ring centred on the inner ring, two
stamped steel cages |
| CCJA, EJA | Flangeless inner ring, guide ring centred on the outer ring
raceway, two stamped steel cages |
| E | Optimized internal design for increased load carrying capacity
213, 222 and 223 series: Flangeless inner ring and two stamped
steel cages. Annular groove and three lubriion holes in the outer
ring.
d ≤ 65 mm: Guide ring centred on the inner ring
d > 65 mm: Guide ring centred on the cage |
| Suffixes - External design (seals, snap ring groove etc.) |
| -CS, -2CS | Contact seal, NBR, on one or both sides |
| -CS2, -2CS2 | Contact seal, FKM, on one or both sides |
| -CS5, -2CS5 | Contact seal, HNBR, on one or both sides |
| K | Tapered bore, taper 1:12 |
| K30 | Tapered bore, taper 1:30 |
Bearing alog :
earing alog :
OUR STOCK
We have more than 4000 square meters of three-dimensional warehouse
and more than 2000 square meters of outdoor warehouse
It ensures that we have sufficient inventory and respond to
customers' needs faster. Fast delivery is our advantage
