EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

Guangzhou Tiangong Machinery Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox from wholesalers

    Buy cheap EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox from wholesalers
    • Buy cheap EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox from wholesalers
    • Buy cheap EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox from wholesalers
    • Buy cheap EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox from wholesalers

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    Ask Lasest Price
    Brand Name : TGFQ
    Model Number : EX400-3 EX400-5 EX450-3
    Price : 500.00-4000.00USD
    Payment Terms : L/C, T/T, D/P, D/A
    Supply Ability : 500 pcs / month
    Delivery Time : 1-3days
    • Product Details
    • Company Profile

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox


    9279943 Hydraulic Planetary Gearbox For Apply EX400-3 EX400-5 EX450-3


    Product parameter:

    Product name:Travel Planetary Gearbox
    Place of Origin:China(Mainland)
    Model:EX400-3 EX400-5 EX450-3
    Part number:9279943 / 9197359 / 9203778
    Motor case:20 Holes
    MOQ:1 PCS
    Payment term:L/C, T/T, D/P, D/A
    Delivery time:Within 1-3 days after receiving the payment
    Means of Transport:
    By Sea, By Air or By Express

    EX450 Planetary Gearbox:

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary GearboxEX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary GearboxEX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary GearboxEX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    Drawing:
    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox
    Parts on group TRAVEL DEVICE (MTH TRACK):
    Pos.
    Part NoQtyParts name
    9197359[2]TRAVEL DEVICE
    9203778[2]TRAVEL DEVICE
    04451685[1]MOTOR;OIL
    21027942[1]HOUSING
    44344155[1]SEAL;GROUP
    51015882[1]DRUM
    74200411[2]BRG.;ROL.
    8J932270[24]BOLT
    9A590922[24]WASHER;SPRING
    103043140[1]NUT
    113043141[1]PLATE;LOCK
    12J901222[2]BOLT
    12J901225[2]BOLT
    131015883[1]CARRIER
    143053195[4]GEAR;PLANETARY
    154452484[8]BRG.;NEEDLE
    164219595[8]PLATE;THRUST
    174263903[4]PIN
    184207947[4]PIN;SPRING
    193053786[1]GEAR;SUN
    211028494[1]SPROCKET
    211010956[1]SPROCKET
    224203187[1]O-RING
    231018360[1]GEAR;RING
    24J931845[30]BOLT
    271015523[1]CARRIER
    284263905[2]SPACER
    293053194[3]GEAR;PLANETARY
    304452483[3]BRG.;NEEDLE
    314201968[6]PLATE;THRUST
    324263902[3]PIN
    334203180[3]PIN;SPRING
    343053785[1]GEAR;SUN
    351024285[1]CARRIER
    373079038[3]GEAR;PLANETARY
    384452480[3]BRG.;NEEDLE
    394269295[6]PLATE;THRUST
    404263901[3]PIN
    414222030[3]PIN;SPRING
    422046005[1]SHAFT;PROP.
    43A590918[4]WASHER;SPRING
    444279343[3]PLUG
    464288767[1]PIN;STOPPER
    49J911860[4]BOLT
    504274541[1]BRG.;BALL
    51991725[1]RING;RETAINING
    52+++++++[1]NAME-PLATE
    53M492564[2]SCREW;DRIVE
    554271596[1]O-RING
    561024284[1]COVER
    574373463[16]BOLT;SHOE

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary GearboxEX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    OUR STOCK

    We have more than 4000 square meters of three-dimensional warehouse and more than 2000 square meters of outdoor warehouse
    It ensures that we have sufficient inventory and respond to customers' needs faster. Fast delivery is our advantage.

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    EX400-3 Excavator Travel Gearbox 24 Holes Hydraulic Planetary Gearbox

    FAQ:
    Q: What can you do?
    A: We can provide you with digging final drive and swing drive motors and reducer gearbox and their parts.


    Q: Hydraulic motors of which brands can be replaced with TGFQ's ones?
    A: Our motors are interchangeable with the motors of the following brands: Doosan, ,KYB, Nachi, Nabtesco, Rexroth, etc.


    Q: Can I order one of our samples for testing first?
    A: Of course!


    Q: How do I order?
    A: You need to tell us the model and quantity you are interested in, and then we will issue a proforma invoice for you. The goods will be prepared after receiving the payment. The preparation time depends on the content of the order.


    Q: Do you have a factory?
    A: Yes, we have our own factory and have 23 years of production experience in the excavated gear industry.
